300200
×
![]()
Discontinued - Replaced By: 400200
Part of the ProMelt ContactorPro Panels Series
Ordering Code: 81012217
UPC: 840213099695
ProMelt ContactorPro Panel 200 Amp
This ProMelt ContractorPro(TM) control panel is designed to control any size snow melting system when connected to a compatible ProMelt Control. The panel has a 200 AMP capacity to operate 120, 208, 240, or 277 VAC snow melting systems. The panel includes a System On indicator light, manual override dial with a 4-hour timer and built-in 24V transformer that provides power to the connected control. The NEMA Type 1 panel measures 12 x 12 x 4 inches and includes knockouts for conduit.
Features
- Protective cover for installation in garages or shops
- Designed for installation with a PM-L3, PM-L2, and PM-L1 control kit
- Compatible with ProMelt mats and cables
- 200 AMP capacity
| Specifications | |
|---|---|
| AMP Capacity | 200.00 |
| Buy American Act Compliant | NO |
| CAProp65-InScope | No |
| Color | Grey |
| Device Type | Controller |
| Programming Capability | Non Programmable |
| UL Listing | N-No UL Code Rating |
-
Literature
